Metal Cage Folding Stackable Heavy Duty Metal Container with PP
Sheet
Steel wire mesh container
Steel wire mesh containers is also named foldable mesh bins, boxes
or wire containers. This product is made of welded mild steel wire
and tubes. Wire mesh side panels fixed with welded U-shaped
stiffener or tubular structure at bottom for strengthening. With or
without lids. Solid pp sheets can be placed inside the panels to
protect fragile goods or easily-scratched-surface goods. This wire
cage container can be designed with open gates/doors or fold down
sides for easy stacking and collapsing during transport and
storage, also for easy access of truck lifts from all sides. With
the use of lift truck or forklifts, this wiremesh container can be
easily used in logistic steps, such as transportation, loading and
unloading, and warehouse storage. The steel mesh containers can be
divided into light type and heavy load containers according to
capacity.
Structures of Foldable Steel Wiremesh Containers
| Product name | Steel wire mesh container |
| Material | Mild Steel Q235 |
| Size | Customized |
| Color | White, Gray, Orange, Blue, Green, Black Etc. (As Customer's Request) |
| Weight | Customized |
| Load capacity | 1000-2000kg |
| Surface Finish | Powder Coated, Electro-Zinc Plated and Hot-Dipped Galvanized. |
| Option | with PP shee |
| Application | Warehouse, Workshop, Factory... |
| Function | Protect fragile goods or easily-scratched-surface goods |
| Delivert time | 20-30 days depends on your quantity |
1. Cap channel over wire perimeter for added protection
2. Square-Stack legs for secure stacking
3. Tags, labels, card holders
4. Casters, fork sleeves, runner bars
5. Dividers or security lids
6. Custom colors
7. Custom feet available.
8. Custom wire mesh size
Regular Size
| Item No. | Size | Folded | Self-weight | Load Capacity | Stackability | Load Quantity | |
| External size(MM) | Internal size(MM) | (MM) | (kg)±2% | (kg) | layers | 40 HC | |
| H-1 | 1600*1150*1075 | 1525*1070*830 | 1600*1150*360 | 125 | 1500 | 3 | 112 |
| H-2 | 1150*800*730 | 1080*720*500 | 1150*800*360 | 70 | 1000 | 4 | 224 |
| H-3 | 1370*900*920 | 1300*820*680 | 1370*900*360 | 107 | 1000 | 4 | 168 |
| H-4 | 1950*1150*1300 | 1875*1070*1030 | 1950*1150*360 | 190 | 1500 | 4 | 80 |
| H-5 | 1200*1000*930 | 1120*920*700 | 1200*1000*370 | 110 | 1200 | 3 | 168 |
| H-6 | 1600*1200*930 | 1525*1120*710 | 1600*1200*370 | 156 | 1500 | 3 | 72 |
| H-7 | 1412*1140*1200 | 1315*1095*1035 | 1412*1140*330 | 110 | 1000 | 3 | 128 |
| H-8 | 1170*1000*760 | 1100*910*580 | 1170*1000*320 | 77 | 1000 | 4 | 168 |
